High Capacity Digital Hanging Scales for Civil Engineering Projects

High Capacity Digital Hanging Scales for Civil Engineering Projects

Civil engineers are responsible for designing, constructing and maintaining roads, bridges, canals, dams and buildings as well as many other construction projects and systems.

The materials they work with are often large and heavy, and must be weighed before they are placed to ensure that each part of the system meets the project’s overall weight requirements and specs.

Generally suspended from a crane, boom or cable in the air, hanging scales are a versatile weighing option that allows operators to lift and weigh large objects simultaneously. This makes construction projects efficient and on schedule.

The crane scales used in a construction environment must be durable, accurate and reliably safe at very high capacities.

Arlyn’s ARC series hanging scales are made with best of class components and sold factory direct, which means you get a higher quality product for less.

Stainless Steel Load Sensors

While the majority of manufacturers use nickel-plated load cells, we manufacture our own weigh sensors from heat-treated stainless steel. This means our load cells have significantly better overload protection, moisture protection, corrosion resistance and durability under all industrial and weather conditions.

Heavy Duty Protective Housing

Built for tough industrial environments, our massive load sensors are sheltered inside an extremely durable housing that is manufactured from a highly visible, solid red, resilient polyurethane and aluminum alloy.

Compared with the sheet metal or cast housing commonly used by other manufacturers, our crane scales offer better corrosion resistance, accuracy, and durability that add years of additional useful life.

High Capacity and Resolution

To achieve the most accurate measurements possible, you should choose a maximum capacity that’s higher than, but as close as possible, to your heaviest load. We offer a range of capacities with three standard models:

•    ARC-2500: With a maximum capacity of 2,500 lbs., this scale offers a resolution of 0.5 lb.
•    ARC-5000: Has a maximum capacity of 5,000 lb. and a 1 lb. resolution
•    ARC-10000: Has an astounding maximum capacity of 10,000 lbs. with a 2 lb. resolution

Superior Accuracy

Manufactured with stainless steel load sensors and advanced digital electronics, our scales offer the highest possible accuracy — 0.1%.

Easy to Use

Available with a variety of optional swivel shackles and hooks, it’s easy to find the setup that will help you get the job done quickly, safely and accurately.

One popular configuration includes our durable welded steel shackle ring and J-hook, which is used to attach and weigh the load. A pivot can also be incorporated into the J-hook design to increase range and ease of loading. A heavy-duty safety catch across the opening of the hook secures the load.

Distance Reading

A large digital LCD display features 1 inch tall graphic numbers, which makes the display easy to read at a distance or from any angle to improve time, effort and efficiency.

Wireless Data Transfer

A USB flash drive can be incorporated into the design of your hanging scale, which will record weight along with time, date, group and item information. To view or share the data, simply remove the USB device and plug it into a workstation PC. The data will automatically be viewable in an easy-to-read Microsoft Excel spreadsheet.

Other Features

•    Pushbutton functions for automatic, keyboard tare, zero functions with memory, net/gross
•    Adjustable display speed of 0.4 seconds
•    Warning message displayed at 102% of scale capacity
•    Multiple weighing unites include pounds, kilos, grams, ounces, etc.
•    No maintenance required because there are no internal moving parts
•    Indoor or outdoor use
•    Operating temperature range of 14°F to 104°F
•    Rechargeable Ni-MH “C” size batteries (2)

Custom Design and Development Available

If your project requires a scale with a capacity, shape or configuration that isn’t widely available, Arlyn Scales’ engineers can work with you to design and develop a custom weighing solution that meets your exact specifications.

Order an Arlyn ARC scale now or contact us about our custom design and development services.
