Veterinary Scales with Light Weight and Accurate Industrial Built Platforms

Starting at $599
Configure and Buy
Electronic Bench Scales for the Food Industry

Overview

Most veterinary scales are foreign made and they look like it. Sheet metal and lower cost components are used to keep the price lower. Arlyn's welded construction and "Weight Average and Hold" functions give durability and accuracy. See more product details
Product Code Capacity & Resolution Platform Size Price
620X-VET 10 lb x 0.002 lb 12" x 16" $599
620T-VET 25 lb x 0.005 lb 12" x 16" $599
620L-VET 50 lb x 0.01 lb 12" x 16" $599
320-VET-SMALL 500 lb x .1lb 20" x 27" $749
320-VET 500 lb x .1 lb 22" x 44" $849
320-VET-LARGE 500 lb x .1 lb 27" x 60" $949
COMBO-VET 22" x 44" and 12" x 16" $1149

***CLICK ON THE PRICE TO AUTO-CONFIGURE YOUR SELECTED MODEL***

***CUSTOM SIZES & CAPACITIES ARE AVAILABLE. CALL US FOR PRICING & DELIVERY***

***CALL US FOR MULTIPLE PLATFORM REQUIREMENTS WITH SINGLE DISPLAY***

Details

Most veterinary scales are foreign made and they look like it. Sheet metal and lower cost components are used to keep the price lower. But most often, a veterinarian is a businessperson. They want to get the best value for their money, not just the lowest cost. Arlyn’s 320-VET scales fit the bill very well. These scales are built in the USA, exactly the same as our industrial heavy-duty scales, with a fully welded corrosion resistant metal frame and special alloy stainless steel load cells. The large, graphical display provides easy to read weights, and the special Animal Weighing function gives highly accurate results, even if the animal will not stay still. Factory direct pricing brings this premium grade scale at an excellent price. All the scales come with a rubber mat for comfortable placement of animals. The smaller 620-VET scale gives similar functions for smaller animals, such as cats, birds and reptiles.

Welded Platform is Lightweight and Portable Yet Strong

(320-VET-SMALL, 320-VET, 320-VET-LARGE) 500 lb x 0.1 capacity. 22” x 44” (Other standard and customized platform sizes are also available). This 24 lb. scale is quite easy to store and move around the office. The height of the platform is only 1 7/8”, so it is easy for animals to step onto scale. A rubber non-skid mat is included to allow the animals to be comfortable while being weighed.

Very Low Height Platform

(620L-VET, 620T-VET, 620X-VET) 10-50 lb capacity. The stainless steel platform is 12” x 16” and is only 1” high. This scale is typically used for smaller animals, such as cats, birds, and reptiles.

Weight Averaging & Hold

The display comes with a built-in option to average the weight over a short period of time (usually 4 seconds). Once the averaging completes, it locks in the weight on the screen for the veterinarian to record the value. The weight remains locked until the vet unlocks the weight by a push of a button. This makes it easy for vets and other users of the scale to weigh animals who are constantly moving and cannot sit still on the scale.

No Moving Parts

In order to provide the best overload capability and shock load capability, the scale uses special alloy stainless steel load cells embedded in welded frame.

Moisture Protection

A rubber gasket is used to seal the display housing. The load sensors are also protected against water and contaminants.

Easy to Read Display

Big, black graphics digits are 1” high. It is easily viewed from any angle, thanks to the stainless steel swivel bracket.

Very High Accuracy

The weight can be read to a resolution of 0.1 lb (320-VET-SMALL, 320-VET, 320-VET-LARGE). The small scales have resolutions ranging from 0.002 – 0.01 lb (1 grams x 5 grams) (620L-VET, 620T-VET, 620X-VET).

Suitable for Weighing Humans

The 320-VET series (especially the 320-VET-SMALL model) is perfectly suitable for weighing humans as well. The low profile platform and small foot print scale is takes up less room in the office and is easy to step on to. The rubber mat on the platform makes it comfortable for people to stand on the scale while being weighed. The Weight Average & Hold feature allows clinicians to average and lock in the weight of the person being weighed even if they cannot stand still on the scale.

AxChange Cloud Monitoring

Monitor and Track your industrial scales on the cloud, anywhere on any device using the new AxChange Cloud Monitoring and Weight Tracking system. Limited free beta accounts available.

Available Upgrades

Display
Outputs
  • Analog Output 4-20mA (or 0-5VDC)
  • RS-232 Serial Port
  • RS-422/RS-485
  • USB Communication (w/ Virtual Serial Communication)
  • Ethernet TCP/IP Connectivity
  • Wireless TCP/IP Connectivity (UpScale)
  • Modbus RTU/ASCII (UpScale)
  • Modbus TCP (UpScale)
Printing
  • Label, Paper and Card Printer (RS232)
  • Bluetooth/USB 58mm Thermal Printer (UpScale)
  • Barcode Functions - Printing and Scanning (UpScale)
Setpoint Control
  • Setpoints (Filling Ops, Relay Ctrl, etc)
  • Relays (AC/DC)
  • Alerts (Buzzer Alarm)
  • Light Tower: 2/3 Light Columns
Counting Operation
  • Parts Counting
Data Collection
Extras
  • Flow Rate Function with Alarms (UpScale)
  • Battery Pack
  • NEMA Stainless Steel Enclosure
  • Remote Buttons (ZERO, TARE, PRINT, CYCLE)
  • 24V Power

Specifications

Brochure & Datasheet 6200 Series Bench Scales (VET) - Specification Sheet (PDF)
MKE-5 Digital Indicator Included 1" high graphics LCD digits. Updates between 0.1 to 0.5 sec. Adjustable.
UPSCALE-9 Indicator Upgrade to Arlyn UpScale 7" Color LCD Touchscreen. Fully Customizable.
Electronic Features 32 bit microcontroller, self test, automatic calibration
Power Requirements 117 VAC 50/60 Hz.
Filter Mode "Weight Average and Hold" for accurately weighing a moving animal
Unit Conversation pounds, kilos, grams, ounces, etc.
Operating Temperature 14°F to 104°F
Minimum Sampling Rate 10 Hz
